LMXD63B500 - Siemens 500A 600V 3 Pole Molded Case Circuit Breaker LMD Frame

LMXD63B500

LMXD63B500 is a Siemens 3 pole molded case circuit breaker rated for 500 amps and 600 volts, designed for reliable power distribution protection.This Siemens LMXD63B500 circuit breaker features a 3-pole configuration with a 500 ampere rating and 600 VAC/500 VDC voltage rating. It uses the LMD frame and includes a thermal magnetic trip unit with a non-interchangeable trip. The breaker has an interrupting rating of 50kA at 480V and 25kA at 600V, suitable for industrial and commercial applications. It is a bolt-on type breaker without installed lugs and is rated for operation at 40°C ambient temperature.

Key Specifications
• Amperage: 500A
• Voltage: 600 VAC / 500 VDC
• Poles: 3
• Frame: LMD
• Mounting Type: Bolt-On
• Interrupt Rating: 50kA at 480V, 25kA at 600V
• Trip Unit: Thermal Magnetic, Non-Interchangeable
• Operating Temperature: 40°C
• Certifications: UL Listed, CSA Certified
• Dimensions (WxHxD): 7.5 x 16 x 4.5 inches
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.




Specifications

• Part Number: LMXD63B500
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : LMXD
• Voltage : 600
• Amperage : 500
• Phase : 3
• Poles : 3
• AIC rating : 50kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : LMD Frame
• Protection : Thermal Magnetic



Product Data

• UPC : 783643304154
• GTIN : 00783643304154
• Country of Origin : Mexico
• Weight : 31.001
