LMXD62B800 - Siemens 800A 600V 2 Pole Molded Case Circuit Breaker LMD Frame

LMXD62B800

LMXD62B800 is a Siemens 2 pole, 800 amp, 600 volt molded case circuit breaker designed for reliable power distribution protection.

This circuit breaker features a thermal magnetic trip unit with a non-interchangeable trip mechanism. It is built on the LMD frame and rated for 50,000 AIC at 480V and 25,000 AIC at 600V, suitable for industrial and commercial applications. The breaker is designed for surface mounting in a NEMA Type 1 enclosure and is rated for operation at 40 degrees Celsius.

• Amperage: 800A
• Voltage: 600V AC
• Poles: 2
• Frame: LMD
• Trip Unit: Thermal Magnetic, Non-Interchangeable
• Interrupt Rating: 50kA at 480V, 25kA at 600V
• Mounting Type: Surface Mount
• Enclosure Type: NEMA Type 1
• Operating Temperature: 40°C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: LMXD62B800
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : LMXD
• Voltage : 600
• Amperage : 800
• Phase : 1
• Poles : 2
• AIC rating : 50kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Frame Size : LMD Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 783643304086
• GTIN : 00783643304086
• Country of Origin : Mexico
• Weight : 26.001
