Product Info
- Manufacturer:Siemens
- Sub-Category:Trip Units & Programmers
Description
LMD63T600
LMD63T600 is a Siemens 3 pole molded case circuit breaker trip unit rated for 600 amps and 600 volts AC, designed for use with LMD6 series breakers.
This interchangeable thermal magnetic trip unit features a 25kA interrupting rating at 600V and is compatible with LMD6 frame types. It provides reliable protection with long-time and instantaneous trip functions suitable for industrial and commercial applications.
- Key Specifications
- Manufacturer: Siemens
- Part Number: LMD63T600
- Amperage: 600A
- Voltage Rating: 600V AC
- Poles: 3
- Interrupting Rating: 25kA @ 600V
- Trip Unit Type: Interchangeable Thermal Magnetic
- Frame Series: LMD6
- Mounting Type: Molded Case
- Voltage Type: AC
- Certifications: UL Listed (implied by Siemens standards)
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: LMD63T600
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Trip Units & Programmers
- Family : Sentron Series
- Type : LMD
- Voltage : 600
- Amperage : 600
- Phase : 3
- Poles : 3
- AIC rating : 50kA@480V
- Connection : Bolt-On
- Functions : LI - Long Time and Instantaneous Trip
- Frame Size : 600
- Amperage Maximum : 600
- Protection : Thermal Magnetic
- Compatible Frames : LMD,HLMD
Product Data
- UPC : 783643268159
- GTIN : 00783643268159
- Country of Origin : Mexico
- Weight : 2.701
- Wire Size : AWG 1/0 to 500KCM, Cu/Al
