Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
LHL36225V
LHL36225V is a 3 pole, 225 amp, 600 volt thermal magnetic circuit breaker from Square D's LHL Series designed for high interrupting capacity applications.This molded case circuit breaker features thermal and magnetic trip functions for overload and short circuit protection. It is rated for 600VAC operation with an interrupting rating of 35kA at 480V. The breaker includes line and load side lug terminals and is suitable for feed-thru connection. It is a unit mount type breaker with a robust LHL frame construction.
- Key Specifications
- Amperage: 225A
- Voltage: 600V AC
- Poles: 3
- Interrupt Rating: 35kA at 480V
- Trip Unit: Thermal Magnetic
- Mounting Type: Unit Mount
- Connection Type: Feed-Thru
- Frame Type: LHL Series
- Part Number: LHL36225V
- Manufacturer : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : LHL Series
- Type : LHL
- Voltage : 600
- Amperage : 225
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
- Dimensions : Depth 17.75 in (450.85 mm) Width 36.62 in (930.15 mm) Height 69.13 in (1755.90 mm)
- Weight : 20
