LHL36225 - Square D 225A 600V 3 Pole Thermal Magnetic Molded Case Circuit Breaker

LHL36225

LHL36225 is a 3 pole, 225 amp, 600 volt thermal magnetic molded case circuit breaker from Square D designed for high interrupting capacity applications.This circuit breaker features a thermal magnetic trip unit with long time and instantaneous trip functions, suitable for overload and short circuit protection. It supports feed-thru connection with line and load side lug terminals and is UL and CSA certified. The breaker frame is LHL series with a 25kA interrupting rating at 600VAC and 50kA at 250VDC, making it reliable for industrial and commercial power distribution.

• Amperage: 225A
• Voltage Rating: 600VAC, 250VDC
• Poles: 3
• Trip Unit: Thermal Magnetic
• Interrupting Rating: 25kA @ 600VAC, 50kA @ 250VDC
• Mounting Type: Unit Mount
• Frame/Series: LHL
• Connection: Feed-Thru with line and load side lugs
• Certifications: UL, CSA
• Dimensions: 6 in width x 5.84 in depth x 11 in height
• High Interrupting Capacity

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LHL36225
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : LHL Series
• Type : LHL
• Voltage : 600
• Amperage : 225
• Phase : 3
• Poles : 3
• AIC rating : kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip Functions
• Frame Size : L Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 785901563273
• GTIN : 00785901563273
• Country of Origin : Mexico
• Dimensions : 11 in (279.4 mm) x 6 in (152.4 mm) x 5.84 in (148.34 mm) (Height x Width x Depth)
• Weight : 7.34
• Wire Size : AWG 1, 600 kcmil aluminium/copper)1, AWG 1, 250 kcmil aluminium/copper)2
