Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
LHF36350
LHF36350 is a Square D molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems.This breaker features a 350A current rating, 600V AC voltage rating, and 3 poles for three-phase applications. It utilizes a bolt-on mounting style for secure installation and is built with an L frame for compatibility with standard enclosures. The thermal magnetic trip unit provides both long-time and instantaneous protection, ensuring effective response to overloads and short circuits. The breaker is rated for high interrupting capacity and is suitable for demanding electrical environments.
- Part Number: LHF36350
- Manufacturer: Square D
- Amperage: 350A
- Voltage: 600V AC
- Poles: 3
- Mounting Type: Bolt-On
- Frame Size: L Frame
- Series: LHF
- Protection Type: Thermal Magnetic
- Interrupt Rating: 35kA @ 480V
- Standards: UL 489, CSA C22.2, IEC 60947-2
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: LHF36350
- Manufacturer : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : LHF Series
- Type : LHF
- Voltage : 600
- Amperage : 350
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
Product Data
- Dimensions : Depth 4 in (101.60 mm) Width 6 in (152.40 mm) Height 12.5 in (317.50 mm)
- Weight : 20
