Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
LHF36300
LHF36300 is a Square D molded case circuit breaker designed for industrial power distribution applications. This 3-pole, 300-amp rated breaker operates at 600 volts AC and features thermal-magnetic trip protection with long-time and instantaneous functions. The LHF36300 utilizes an I-Line style plug-in connection and delivers a 35 kiloamp interrupting capacity at 480 volts, making it suitable for high-demand electrical systems. Key Specifications
- Part Number: LHF36300
- Manufacturer: Square D
- Poles: 3
- Amperage: 300 Amp
- Voltage Rating: 600 Volt AC, 250 Volt DC
- Interrupting Rating: 35 kA at 480V
- Trip Unit: Thermal-Magnetic with Long-Time and Instantaneous functions
- Connection Type: I-Line Style Plug-In
- Frame Type: L Frame
- Certifications: UL, CSA
- Dimensions: 12.5 inches H x 6.0 inches W x 4.0 inches D
- Weight: 16 lbs
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: LHF36300
- Manufacturer : Square D
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : LHF Series
- Type : LHF
- Voltage : 600
- Amperage : 300
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
Product Data
- Dimensions : Depth 4 in (101.60 mm) Width 6 in (152.40 mm) Height 12.5 in (317.50 mm)
- Weight : 20
