Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
LH36225CBA
LH36225CBA is a Square D 3 pole molded case circuit breaker rated for 225 amps at 600VAC with I-Line style plug-in mounting. LH36225CBA delivers thermal magnetic protection with long-time and instantaneous trip functions, designed for industrial and commercial power distribution applications requiring reliable overcurrent protection. This breaker features a 35kA interrupting rating at 480V and meets UL 489, CSA, and IEC standards for safety and performance. Key Specifications
- Amperage: 225A
- Voltage: 600VAC, 250VDC
- Poles: 3
- Phase: 3 Phase
- Frame Type: LH
- Mounting Type: I-Line Style Plug-In
- Protection Type: Thermal Magnetic
- Trip Functions: LI - Long-Time and Instantaneous
- Interrupting Rating: 35kA at 480V
- Certifications: UL, CSA, IEC
- Standards: RoHS, HACR
Specifications
- Part Number: LH36225CBA
- Manufacturer : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : I-Line
- Type : LH
- Voltage : 600
- Amperage : 225
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : I-Line Style Plug-In
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 28
