LGS3350FAG - Cutler Hammer 350A 3-Pole LG Frame Molded Case Circuit Breaker 600V Series G

LGS3350FAG

LGS3350FAG is a Cutler Hammer Series G molded case circuit breaker designed for reliable power distribution protection.This 3-pole LG frame breaker features a 350 ampere rating with thermal magnetic trip unit, suitable for 50/60 Hz applications. It offers high interrupt ratings of 85 kAIC at 240 VAC, 50 kAIC at 480 VAC, and 25 kAIC at 600 VAC. The breaker includes line and load side lug terminals and metric mounting hardware. It is UL listed, CSA certified, IEC rated, and CE marked, ensuring compliance with industry standards. The breaker is HACR rated and 80% rated for flexible application.

Key Specifications
• Amperage: 350 A
• Voltage Rating: 600 VAC max
• Poles: 3
• Frame Type: LG
• Series: Series G
• Interrupt Rating: 85 kAIC @ 240 VAC, 50 kAIC @ 480 VAC, 25 kAIC @ 600 VAC
• Trip Unit: Thermal Magnetic (T185)
• Mounting Hardware: Metric
• Frequency: 50 to 60 Hz
• Terminals: Line and Load Side Lugs
• Certifications: UL Listed, CSA Certified, IEC Rated, CE Marked
• HACR Rated

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LGS3350FAG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : LGS
• Voltage : 600
• Amperage : 350
• Phase : 3
• Poles : 3
• AIC rating : 50kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 782116142576
• GTIN : 00782116142576
• Country of Origin : United States
• Dimensions : 12 in x 6.5 in x 7.5 in (Length/Depth x Height x Width)
• Weight : 15
• Certification : UL Listed,CSA Certified,IEC Rated,CE Marked
