LGH3300FAG - Cutler Hammer 300A 3-Pole LG-Frame Series G Molded Case Circuit Breaker 100 kAIC 240V

LGH3300FAG

LGH3300FAG is a Cutler Hammer Series G complete molded case circuit breaker with a 300 amp rating and three poles.This LG-frame breaker features fixed thermal and adjustable magnetic trip units, 80% rating, and is designed for line and load applications. It offers high interrupt ratings of 100 kAIC at 240 Vac, 65 kAIC at 480 Vac, and 35 kAIC at 600 Vac. The breaker is metric mounted and certified to CSA, UL, and IEC standards, with CE marking and HACR rating.

Key Specifications
• Amperage: 300 A
• Voltage: Rated for 240 Vac, 480 Vac, and 600 Vac
• Poles: Three-pole
• Mounting Type: Metric
• Interrupt Rating: 100 kAIC @ 240 Vac, 65 kAIC @ 480 Vac, 35 kAIC @ 600 Vac
• Series/Frame: Series G, LG-frame
• Trip Unit: Fixed thermal, adjustable magnetic (T185)
• Certifications: CSA Certified, UL Listed, IEC Rated, CE Marked
• Rating: 80% rated
• Terminal Type: Line and load
• Frequency: 50/60 Hz
• HACR Rated

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LGH3300FAG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : LGH
• Voltage : 600
• Amperage : 300
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 782116142743
• GTIN : 00782116142743
• Country of Origin : United States
• Dimensions : 4.09 in x 5.48 in x 5.48 in (Length/Depth x Height x Width)
• Weight : 16
• Certification : IEC Rated,CSA Certified,UL Listed,CE Marked
