LGE3350FAG - Cutler Hammer 350A 600V 3-Pole LG-Frame Molded Case Circuit Breaker, Fixed Thermal Adjustable Magnetic Trip, 65kAIC at 240V

LGE3350FAG

LGE3350FAG is a Cutler Hammer Series G LG-frame molded case circuit breaker rated for 350 amps and 600 volts with three poles.This complete breaker features a fixed thermal and adjustable magnetic trip unit, designed for reliable protection in industrial and commercial applications. It supports line and load connections with metric mounting hardware and operates at 50/60 Hz frequency. The breaker has an interrupt rating of 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, and 18 kAIC at 600 Vac. It is UL listed, CSA certified, IEC rated, CE marked, and HACR rated for HVAC applications.

Key Specifications
• Amperage: 350 A
• Voltage: 600 Vac max
• Poles: 3
• Frame: LG
• Series: Series G
• Trip Type: Fixed thermal, adjustable magnetic (T185)
• Interrupt Rating: 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, 18 kAIC at 600 Vac
• Mounting: Metric hardware
• Frequency: 50/60 Hz
• Certifications: UL Listed, CSA Certified, IEC Rated, CE Marked
• HACR Rated: Yes

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LGE3350FAG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : LGE
• Voltage : 600
• Amperage : 350
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Line/Load Lug
• Frame Size : 400A/LG
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 500 MCM Max. Wire Size 750 MCM
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 782116142392
• GTIN : 00782116142392
• Country of Origin : United States
• Dimensions : 4.09 in x 5.48 in x 5.48 in (Length/Depth x Height x Width)
• Weight : 14.5
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
• Wire Size : 500 MCM-750 MCM
