2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
LGB2K020B
LGB2K020B is a Siemens 2-pole molded case circuit breaker rated for 20 amps and 600 volts, designed for reliable circuit protection in industrial and commercial applications. LGB2K020B features a thermal-magnetic trip unit within the GB2 series frame, offering high interrupting capacity and compliance with UL489 certification standards.
- Key Specifications
- Amperage: 20 Amps
- Voltage Rating: 600Y/347V AC
- Number of Poles: 2
- Interrupt Rating: 65kA at 480V
- Series/Frame: GB2 (LGB Frame)
- Trip Unit: Thermal-Magnetic
- Mounting Type: Panelboard Mount
- Certifications: UL489 Listed
- Application: Low Voltage Circuit Protection
- Part Number: LGB2K020B
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : GB2 Series
- Type : GB2
- Voltage : 600
- Amperage : 20
- Phase : 1
- Poles : 2
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Frame Size : GB2 Frame
- Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
- Protection : Thermal Magnetic
- UPC : 804766340185
- GTIN : 00804766340185
- Country of Origin : Mexico
- Dimensions : 2.87 x 1.969 x 4.988 inch
- Weight : 1.852
- Certification : UL, CSA, IEC, NOM
- Wire Size : 14 to 10 AWS, Cu/Al
