LES3600LSG - Cutler Hammer 600A 600VAC 3-Pole Series C Circuit Breaker Trip Unit LSG Function

LES3600LSG

LES3600LSG is a Cutler Hammer Series C molded case circuit breaker trip unit with 600 ampere rating and 600VAC maximum voltage, designed for 3-pole applications.This trip unit features LSG function providing adjustable long-time, short-time, and ground fault protection. It fits Series C frame types including LD, HLD, LDC, CLD, CHLD, and CLDC. The unit has a magnetic trip adjustment and requires a rating plug for operation. It offers high interrupting capacity with ratings up to 100kA at 240VAC.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Series/Frame: Series C, LES frame
• Amperage: 600 Amps max
• Voltage: 600 VAC max
• Poles: 3
• Trip Unit Type: LSG (Long-time, Short-time, Ground Fault)
• Interrupting Capacity: 100kA @ 240VAC, 65kA @ 480VAC, 35kA @ 600VAC
• Mounting Type: Bolt On
• Trip Adjustment: Magnetic trip adjustment
• Weight: Approximately 7.23 lbs
• Dimensions: 9.5" x 5.5" x 9"
• Certifications: Meets Series C molded case breaker standards

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LES3600LSG
• Manufacturer : Cutler Hammer
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Trip Units & Programmers
• Family : Series C
• Type : LD63
• Voltage : 600VAC
• Amperage : 600
• Phase : 3
• Poles : 3
• Functions : LSG - Long-Time, Short-Time and Ground Fault Trip
• Amperage Maximum : 600
• Amperage Minimum : 600
• Protection : Solid State
• Compatible Frames : LES

Product Data

• UPC : 786679281406
• GTIN : 00786679281406
• Country of Origin : United States
• Dimensions : 9 in x 9.5 in x 5.5 in (Length/Depth x Height x Width)
• Weight : 7.23
• Certification : UL Listed
