Description
LEN00C003120B
LEN00C003120B is a Siemens 30A lighting contactor designed for reliable switching of lighting loads in commercial and industrial applications.
This electrically held contactor features three normally open (NO) poles, a 110/120VAC coil, and is rated for up to 600VAC. It is a non-combination type with no built-in disconnect, supplied in an open (NEMA type) enclosure. The unit is suitable for installation at altitudes up to 6560 ft and operates within a temperature range of 32 to 104°F (0 to 40°C).
-
Key Specifications
- Amperage: 30A
- Voltage: 110/120VAC coil, 600VAC main circuit
- Poles: 3 NO (normally open), 0 NC
- Mounting Type: Open enclosure (NEMA type)
- Interrupt Rating: Not specified in available data
- Series/Frame: Not specified in available data
- Trip Unit: Not applicable (electrically held contactor)
- Certifications: Not specified in available data
- Coil Power: 87VA pickup, 9.4VA holding
- Mechanical Life: 10,000,000 switching cycles (typical)
- Country of Origin: Germany
- Weight: 1 lb
- Dimensions: 3.47 x 1.84 x 3.96 in
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: LEN00C003120B
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Class LE
- Type : LEN00C
- Voltage : 600
- Amperage : 30
- Phase : 3
- Poles : 3
- Coil Voltage Maximum : 120
- Coil Voltage Minimum : 120
Product Data
- UPC : 040892859812
- GTIN : 00040892859812
- Country of Origin : Germany
- Weight : 1.014
