LE36100LSG - Square D 100 Amp 600 Volt 3 Pole Molded Case Circuit Breaker LSIG Trip I-Line Plug-In

LE36100LSG

LE36100LSG is a Square D molded case circuit breaker designed for reliable power distribution protection.This circuit breaker features a 100 amp rating, 600 volt capacity, and 3 poles with I-Line style plug-in mounting. It includes LSIG trip functions (Long-Time, Short-Time, Instantaneous, and Ground Fault) with a 65kA interrupt rating at 480 volts. The breaker belongs to the Type LE series and is suitable for three-phase applications, providing high interrupting capacity and full Micrologic Series B electronic trip unit functionality.

Key Specifications
• Amperage: 100 Amp
• Voltage: 600 Volt
• Poles: 3
• Mounting Type: I-Line Style Plug-In
• Interrupt Rating: 65kA @ 480V
• Series/Frame: Type LE
• Trip Unit: LSIG (Long-Time, Short-Time, Instantaneous, Ground Fault)
• Phase: 3 Phase
• Certifications: UL 489, ANSI C37, NETA standards compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LE36100LSG
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Micrologic
• Type : LE
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Protection : Solid State

Product Data

• GTIN : 00785901082033
• Country of Origin : United States
• Dimensions : Depth 5.38 in (136.65 mm) x Width 5.64 in (143.26 mm)
• Weight : 30.001
