LDC4600F - Eaton Series C LDC Frame Only 4-Pole 600A 600VAC Fixed Thermal Magnetic Trip

LDC4600F

LDC4600F is a Series C LDC molded case circuit breaker frame, designed for reliable electrical protection in industrial and commercial applications. This frame-only unit is built for four-pole configurations and features fixed thermal and fixed magnetic trip settings for consistent performance. The Eaton LDC4600F is engineered for high amperage loads up to 600A and supports a maximum voltage of 600VAC. It is suitable for use in systems requiring robust circuit protection with a compact, durable frame. The breaker is UL 489 listed and designed for use in a wide range of electrical environments.

• Amperage Rating: 600A
• Voltage Rating: 600VAC, 250VDC
• Number of Poles: Four-pole
• Series/Frame: Series C, L Frame
• Interrupt Rating: 100kAIC at 480VAC
• Mounting Type: Frame only
• Frequency Rating: 50-60 Hz
• Trip Unit: Fixed thermal, fixed magnetic
• Certifications: UL 489
• Product Dimensions: 8.25 in x 4.06 in x 8.25 in
• Product Weight: 0.01 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item is Frame only as definded by the part number. That means it is only the circuit breaker frame, and no lugs or trip unit is included with the frame.

Specifications

• Part Number: LDC4600F
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : LDC
• Voltage : 600
• Amperage : 600
• Phase : 3
• Poles : 4
• AIC rating : 100kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : L Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679148242
• GTIN : 00786679148242
• Country of Origin : United States
• Dimensions : 8.25 in x 8.25 in x 4.06 in (Length/Depth x Height x Width)
• Weight : 0.01
• Certification : UL 489
