LDB3500W - Eaton Series C L-Frame Molded Case Circuit Breaker 3-Pole 500A

LDB3500W

LDB3500W is an Eaton Series C L-frame molded case circuit breaker designed for three-pole power distribution applications with a 500-ampere rating.

This complete molded case circuit breaker features fixed thermal and fixed magnetic trip protection, delivering reliable overcurrent protection for industrial and commercial electrical systems. The L-frame design provides compact mounting in standard distribution enclosures. Rated for 50 to 60 Hz operation, the LDB3500W offers interrupt ratings of 65 kAIC at 240 Vac and 35 kAIC at 480 Vac, ensuring safe fault clearing across multiple voltage levels. The breaker comes without terminals, allowing for flexible installation configurations.

• Amperage Rating: 500 A
• Number of Poles: Three-pole
• Frame Type: L-frame
• Series: Series C
• Trip Type: Fixed thermal, fixed magnetic
• Interrupt Rating: 65 kAIC at 240 Vac, 35 kAIC at 480 Vac
• Frequency Rating: 50 to 60 Hz
• Certifications: UL 489
• Terminals: Without terminals
• Dimensions: 8.25 in x 8.25 in x 8.25 in
• Weight: 20 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: LDB3500W
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : LDB
• Voltage : 600
• Amperage : 500
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : L Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679148273
• GTIN : 00786679148273
• Country of Origin : United States
• Dimensions : 8.25 in x 8.25 in x 8.25 in (Length/Depth x Height x Width)
• Weight : 20
• Certification : UL 489
