LDB2450X - Eaton Series C L-Frame 450A 2-Pole Molded Case Circuit Breaker 600V 65kAIC 240V 35kAIC 480V Fixed Thermal Magnetic Trip UL 489

LDB2450X

LDB2450X is a Series C L-frame molded case circuit breaker designed for reliable protection in commercial and industrial applications. This Eaton breaker features a fixed thermal and fixed magnetic trip unit, two poles, and a 450A current rating, making it suitable for demanding electrical environments. The Eaton LDB2450X is rated for 600 Vac and 250 Vdc, with an interrupt rating of 65 kAIC at 240 Vac and 35 kAIC at 480 Vac. It is built with aluminum terminals and supports both line and load connections. The breaker is certified to UL 489 standards and operates at 50/60 Hz. Its robust design and compatibility with a wide range of accessories make it ideal for heavy-duty installations.

• Series C L-frame molded case circuit breaker
• 450A amperage rating
• Two-pole configuration
• 600 Vac, 250 Vdc voltage rating
• 65 kAIC interrupt rating at 240 Vac
• 35 kAIC interrupt rating at 480 Vac
• Fixed thermal and fixed magnetic trip unit
• UL 489 certified
• Aluminum terminals
• Line and load connections
• 50/60 Hz frequency rating

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LDB2450X
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : LDB
• Voltage : 600
• Amperage : 450
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : L Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 782114893012
• GTIN : 00782114893012
• Country of Origin : United States
• Dimensions : 8.25 in x 8.25 in x 8.25 in (Length/Depth x Height x Width)
• Weight : 18
• Certification : UL 489
