Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
LD2450
LD2450 is a complete molded case circuit breaker from Eaton designed for reliable electrical protection in industrial and commercial applications.This Eaton Series C L-frame breaker features a fixed thermal and fixed magnetic trip unit, providing consistent and durable overload and short-circuit protection. It is rated for 450 amps and supports voltages up to 600 VAC and 250 VDC. The breaker has two poles and an interrupt rating of 65 kAIC at 240 VAC and 35 kAIC at 480 VAC, making it suitable for demanding electrical environments. Constructed with aluminum terminals for line and load connections, it operates at 50/60 Hz frequency.
- Manufacturer: Eaton
- Part Number: LD2450
- Series: Series C
- Frame Type: L-Frame
- Amperage: 450 Amp
- Voltage Rating: 600 VAC / 250 VDC
- Poles: 2
- Trip Type: Fixed thermal, fixed magnetic
- Interrupt Rating: 65 kAIC at 240 VAC, 35 kAIC at 480 VAC
- Terminal Material: Aluminum
- Frequency: 50/60 Hz
- Certifications: UL 489
Specifications
- Part Number: LD2450
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : LD
- Voltage : 600
- Amperage : 450
- Phase : 1
- Poles : 2
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 782114263235
- GTIN : 00782114263235
- Country of Origin : United States
- Dimensions : 10.75 in x 8.25 in x 4.06 in (Length/Depth x Height x Width)
- Weight : 0.01
- Certification : UL 489
