LC1D32P7C - Schneider Electric TeSys D 3-Pole 32A 690V AC Contactor with 230V AC Coil

LC1D32P7C

This IEC contactor features 3 normally open (3 NO) contacts suitable for AC-3 motor control up to 440V and 690V, with a maximum current of 32A at 60¡C. It supports motor power ratings up to 18.5 kW at 690V AC and 10 HP at 230/240V AC for three-phase motors. The contactor includes screw clamp terminals for secure wiring and operates with a coil voltage of 230V AC at 50/60 Hz. It offers mechanical durability of 15 million cycles and a high operating rate of 3600 cycles per hour at 60¡C. The device complies with IEC 60335-1 for fire resistance and features improved mechanical robustness and flame retardance.

• Contactor Type: TeSys D, non-reversing
• Number of Poles: 3 (3 Normally Open contacts)
• Current Rating: 32 A AC-3
• Voltage Rating: Up to 690 V AC
• Coil Voltage: 230 V AC, 50/60 Hz
• Motor Power: 18.5 kW at 690 V AC, 10 HP at 230/240 V AC (3-phase)
• Mounting: Screw clamp terminals, panel or DIN rail mountable
• Mechanical Durability: 15 million cycles

Specifications

• Part Number: LC1D32P7C
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Motor Control
• Item Subcategory : Contactor
• Family : TeSys D
• Type : LC1D
• Voltage : 600
• Amperage : 32
• Phase : 3
• Poles : 3
• Coil Voltage Maximum : 230
• Coil Voltage Minimum : 230



Product Data

• Weight : 0.904
• Certification : CE, UKCA, CCC
