LC1D32CC7C - Schneider Electric TeSys Deca 3-Pole 32A 36V AC Contactor

LC1D32CC7C

LC1D32CC7C is a 3-pole TeSys Deca contactor designed for motor control applications up to 32A at 440V with a 36V AC coil. This industrial-grade contactor provides reliable switching for motors, heating, lighting, and other inductive loads in automation and control panels. The unit features 1 normally open and 1 normally closed auxiliary contact for enhanced control flexibility and is rated for up to 15kW at 400V in AC-3 duty. Key Specifications

• Poles: 3 (3NO main contacts)
• Rated Current: 32A AC-3
• Coil Voltage: 36V AC 50/60Hz
• Maximum Voltage: 440V
• Rated Insulation Voltage: 690V
• Auxiliary Contacts: 1NO + 1NC
• Mounting: DIN Rail (35/60/70mm)
• Power Rating: 15kW at 380/400V
• Certifications: CE, EN 61095
• Operating Life: 10 million mechanical operations

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LC1D32CC7C
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Motor Control
• Item Subcategory : Contactor
• Family : TeSys D
• Type : LC1D
• Voltage : 600
• Amperage : 32
• Phase : 3
• Poles : 3
• Coil Voltage Maximum : 36
• Coil Voltage Minimum : 36

Product Data

• Weight : 0.884
• Certification : CE, UKCA, CCC
