Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
LAL36350V
LAL36350V is a Square D 350 Amp, 600 Volt, 3-Pole thermal magnetic molded case circuit breaker designed for reliable circuit protection.This circuit breaker features a LAL series frame with thermal-magnetic trip unit technology, providing long-time and instantaneous trip functions. It is unit mount with line and load side lug connections, suitable for 3-phase applications. The breaker has an interrupt rating of 22kA at 600VAC and 10kA at 250VDC, ensuring robust fault current interruption.
- Key Specifications
- Amperage: 350 Amp
- Voltage Rating: 600 VAC / 250 VDC
- Poles: 3
- Frame Type: LAL Series
- Trip Unit Technology: Thermal Magnetic
- Mounting Type: Unit Mount
- Interrupt Rating: 22kA @ 600VAC, 10kA @ 250VDC
- Connection: Line and Load Side Lugs
- Trip Functions: Long-Time and Instantaneous (LI)
- Part Number: LAL36350V
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : LAL Series
- Type : LAL
- Voltage : 600
- Amperage : 350
- Phase : 3
- Poles : 3
- AIC rating : 30kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
- UPC : 785901358336
- GTIN : 00785901358336
- Country of Origin : Mexico
- Dimensions : Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
- Weight : 20
