Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
LAL361501021
LAL361501021 is a 3-pole, 150 amp, 600 volt molded case circuit breaker from Square D designed for reliable thermal magnetic protection.This circuit breaker features a 30kA interrupting rating at 480 volts and is part of the LAL series frame. It provides robust protection for industrial and commercial electrical systems with a thermal magnetic trip unit and is suitable for use in 3-pole applications requiring up to 150 amps.
- Key Specifications
- Amperage: 150 Amps
- Voltage Rating: 600 Volts AC
- Number of Poles: 3
- Interrupting Rating: 30kA at 480V
- Frame/Series: LAL
- Trip Unit: Thermal Magnetic
- Mounting Type: Molded Case
- Certifications: UL Listed, CSA Certified (typical for Square D MCCBs)
- Part Number: LAL361501021
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : LAL Series
- Type : LAL
- Voltage : 600
- Amperage : 150
- Phase : 3
- Poles : 3
- AIC rating : 30kA@480V
- Connection : Feed-Thru
- Functions : Long Time and Instantaneous Trip_
- Frame Size : L Frame
- Protection : Thermal Magnetic
- UPC : 060648628741
- GTIN : 03606486287415
- Country of Origin : Mexico
- Dimensions : 11 in (279.4 mm) x 6 in (152.4 mm) x 5.84 in (148.34 mm) (Height x Width x Depth)
- Weight : 16.766
Additional Information
complete with 120/240 Vac shunt trip
