LA3225PT - Westinghouse 225A 600V 3 Pole Molded Case Circuit Breaker with Trip Unit

LA3225PT

LA3225PT is a Westinghouse 3 pole molded case circuit breaker rated for 225 amps and 600 volts. It features a thermal magnetic trip unit for reliable protection.

This circuit breaker is part of the Westinghouse LA series, designed for bolt-on mounting and equipped with interchangeable trip units offering long-time and instantaneous trip functions. It has a frame rating of 400 amps and a trip rating of 225 amps, suitable for industrial and commercial electrical distribution applications. The breaker provides interrupting capacity compatible with standard ratings for 600V systems.

• Manufacturer: Westinghouse
• Part Number: LA3225PT
• Amperage: 225A trip rating
• Voltage Rating: 600V AC
• Poles: 3
• Frame Rating: 400A
• Mounting Type: Bolt-On
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous functions
• Series/Frame: LA Series

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LA3225PT
• Manufacturer : Westinghouse
• Brand : Westinghouse
• Category : Circuit Breaker
• Item Subcategory : Trip Units & Programmers
• Family : TRI-PAC
• Type : LA
• Voltage : 600
• Poles : 3
• Functions : LI - Long-Time and Instantaneous
• Frame Size : 225
• Amperage Maximum : 225
• Amperage Minimum : 225
• Protection : Thermal Magnetic
• Compatible Frames : LA,HLA

Product Data

• UPC : 786679766163
• GTIN : 00786679766163
• Country of Origin : United States
• Dimensions : 10.1 in x 5.3 in x 5.3 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL 489
