Product Info
- Manufacturer:American/Federal Pacific
- Sub-Category:Molded Case
Description
KG3400
KG3400 is a 3 pole, 400 amp, 600 volt circuit breaker manufactured by American Federal Pacific, designed for reliable power distribution protection.This KG series molded case circuit breaker features a K-frame design with a thermal-magnetic trip unit. It supports a maximum interrupt rating of 14kA at 480V and 18kA at 240V, suitable for generator and industrial applications. The breaker is rated for 60 Hz frequency and provides line/load interchangeable connections.
- Amperage: 400A
- Voltage: 600V AC
- Poles: 3
- Interrupt Rating: 14kA at 480V, 18kA at 240V
- Frame/Series: K-Frame, KG Series
- Trip Unit: Thermal-Magnetic
- Frequency: 60 Hz
- Mounting Type: Feed-Thru
- Application: Generator Breaker
- Line/Load: Interchangeable
- Certifications: Industry standard compliant
Specifications
- Part Number: KG3400
- Manufacturer : American/Federal Pacific
- Brand : American/Federal Pacific
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : KG
- Voltage : 600
- Amperage : 400
- Phase : 3
- Poles : 3
- AIC rating : 14kA@480V
- Connection : Feed-Thru
- Functions : Reverse
- Protection : Thermal Magnetic
Product Data
- UPC : 786679197141
- GTIN : 00786679197141
- Country of Origin : Dominican Republic
- Weight : 13.24
- Certification : UL, CSA, IEC
