KDC3100Y - Eaton 100 Amp 3 Pole 600 Volt Molded Case Circuit Breaker K-Frame

KDC3100Y

KDC3100Y is a 100 Amp, 3 Pole, 600 Volt molded case circuit breaker from Eaton's K-Frame Series C line.

This Eaton Cutler-Hammer Series C complete molded case circuit breaker features a fixed thermal and fixed magnetic trip type with thermal magnetic protection. It is designed for 3-phase applications with a 600 Vac and 250 Vdc voltage rating. The breaker includes interchangeable long-time and instantaneous trip functions (LI) and line and load side lug terminals for feed-thru connections. It has a 35 kA interrupting rating at 480 V and 65 kA at 240 V, suitable for standard interrupting capacity at 40 degrees Celsius.

• Amperage: 100 A
• Voltage: 600 Vac / 250 Vdc
• Poles: 3
• Frame Type: K-Frame
• Series: Series C
• Trip Unit: Fixed Thermal / Fixed Magnetic with LI functions
• Interrupt Rating: 35 kA at 480 V, 65 kA at 240 V
• Mounting Type: Bolt-On
• Connection: Feed-Thru, line and load side lug terminals
• Frequency: 50/60 Hz
• Weight: 11.5 lbs
• Dimensions (HxWxD): 10.13" x 5.5" x 4.13"

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: KDC3100Y
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : KDC
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : K Frame
• Protection : Thermal Magnetic

Product Data

• Weight : 12
