Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
KDB3125L
KDB3125L is a Series C K-Frame molded case circuit breaker designed for industrial and commercial power distribution applications. This 3-pole unit features thermal magnetic trip protection with long-time and instantaneous characteristics, delivering reliable overcurrent protection at 125 amperes and 600VAC maximum voltage rating. The non-interchangeable trip unit ensures consistent performance across 50/60Hz systems at 40 degrees Celsius. Key Specifications
- Manufacturer: Eaton Cutler-Hammer
- Part Number: KDB3125L
- Frame Type: K-Frame Series C
- Amperage: 125A
- Voltage: 600VAC
- Poles: 3-Pole
- Trip Unit: Thermal Magnetic
- Interrupt Rating: 25KAIC @ 600V
- Interrupt Rating: 35KA @ 480VAC
- Interrupt Rating: 65KA @ 240VAC
- Frequency: 50/60Hz
- Configuration: Feed-Thru
Specifications
- Part Number: KDB3125L
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : KDB
- Voltage : 600
- Amperage : 125
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : K Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 13
