KDB2300W - Eaton Series C K-Frame Molded Case Circuit Breaker 2-Pole 300A 600VAC Fixed Thermal Magnetic Trip

KDB2300W

KDB2300W is a Series C K-frame molded case circuit breaker designed for reliable electrical protection in industrial and commercial applications. This two-pole breaker features a fixed thermal and fixed magnetic trip unit for consistent performance and safety. The Eaton KDB2300W is engineered for use in systems requiring a 300 ampere rating and a maximum voltage of 600 VAC. It is suitable for a wide range of power distribution environments and offers robust interrupt ratings for dependable circuit protection.

• Amperage Rating: 300 A
• Number of Poles: Two-pole
• Voltage Rating: 600 Vac, 250 Vdc
• Interrupt Rating: 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, 25 kAIC at 600 Vac
• Series/Frame: Series C, K-frame
• Mounting Type: Complete breaker (without terminals)
• Frequency Rating: 50 to 60 Hz
• Product Weight: 11.5 lb
• Product Height: 5.5 in
• Product Width: 5.5 in
• Product Depth: 4.1 in
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: KDB2300W
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : KDB
• Voltage : 600
• Amperage : 300
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : K Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679612033
• GTIN : 00786679612033
• Country of Origin : Dominican Republic
• Dimensions : 4.1 in x 5.5 in x 5.5 in (Length/Depth x Height x Width)
• Weight : 11.5
• Certification : UL Listed
