KDB2200W - Eaton Series C 2-Pole 200A 600VAC Molded Case Circuit Breaker

KDB2200W

KDB2200W is an Eaton Series C K-frame molded case circuit breaker designed for industrial and commercial power distribution applications. This two-pole breaker provides reliable overcurrent protection with a fixed thermal trip unit and is rated for 200 amperes at 600 volts AC or 250 volts DC. The KDB2200W delivers interrupt ratings of 35 kAIC at 480 VAC and 65 kAIC at 240 VAC, making it suitable for demanding electrical systems requiring high fault current capacity. Built to Series C specifications, this breaker combines durability with consistent performance in standard mounting configurations.

• Amperage Rating: 200 A
• Voltage Rating: 600 VAC / 250 VDC
• Poles: 2
• Circuit Breaker Type: KDB
• Series: C K-Frame
• Trip Unit: Fixed Thermal
• Interrupt Rating: 35 kAIC at 480 VAC, 65 kAIC at 240 VAC
• Frequency: 50/60 Hz

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: KDB2200W
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : KDB
• Voltage : 600
• Amperage : 200
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : K Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679612002
• GTIN : 00786679612002
• Country of Origin : Dominican Republic
• Dimensions : 4.1 in x 5.5 in x 5.5 in (Length/Depth x Height x Width)
• Weight : 11.5
• Certification : UL Listed
