Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
KDB2175
KDB2175 is an Eaton Series C, K-frame molded case circuit breaker designed for industrial and commercial power distribution applications. This two-pole breaker provides reliable overcurrent protection with fixed thermal and fixed magnetic trip units, delivering consistent performance in demanding electrical systems.Technical Overview
The KDB2175 features a robust K-frame design rated for 175 amperes at 600 Vac and 250 Vdc, making it suitable for a wide range of voltage applications. With an interrupt rating of 35 kAIC at 480V and 65 kAIC at 240V, this breaker handles significant fault currents while maintaining system integrity. The non-interchangeable thermal magnetic trip mechanism ensures precise load protection and rapid fault clearing. Aluminum terminals provide excellent conductivity and corrosion resistance for long-term reliability.
- Amperage Rating: 175 A
- Voltage Rating: 600 Vac, 250 Vdc
- Number of Poles: Two-pole
- Frame Type: K-frame
- Series: Series C
- Trip Type: Fixed thermal, fixed magnetic
- Interrupt Rating: 35 kAIC at 480V, 65 kAIC at 240V
- Frequency Rating: 50 to 60 Hz
- Terminal Material: Aluminum
- Certifications: UL Listed
- Dimensions: 5.5 in H x 5.5 in W x 4.1 in D
- Weight: 11.5 lb
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: KDB2175
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : KDB
- Voltage : 600
- Amperage : 175
- Phase : 1
- Poles : 2
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : K Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679349236
- GTIN : 00786679349236
- Country of Origin : Dominican Republic
- Dimensions : 4.1 in x 5.5 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 11.5
- Certification : UL Listed
