KD2200 - Eaton 200A 600VAC 2-Pole Molded Case Circuit Breaker Series C

KD2200

KD2200 is a 2-pole molded case circuit breaker from Eaton's Series C, rated for 200 amps and 600 VAC operation.This Eaton KD2200 circuit breaker features a thermal magnetic trip unit (T186) designed for reliable protection in industrial and commercial electrical systems. It supports 200 amps continuous current with a voltage rating of 600 VAC and 250 VDC. The breaker has a bolt-on mounting type and offers interrupt ratings of 65 kA at 240 VAC and 35 kA at 480 VAC, ensuring high fault current interruption capability. It is part of Eaton's K-frame complete breaker family and meets industry certifications for safety and performance.

Key Specifications
• Amperage: 200 A
• Voltage Rating: 600 VAC, 250 VDC
• Poles: 2
• Mounting Type: Bolt-on
• Interrupt Rating: 65 kA at 240 VAC, 35 kA at 480 VAC
• Series/Frame: Eaton Series C, K-frame
• Trip Unit: Thermal Magnetic (T186)
• Breaker Type: Molded Case Circuit Breaker (Type KD)
• Weight: Approximately 10 lbs
• Certifications: Industry standard safety certifications
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: KD2200
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : KD
• Voltage : 600
• Amperage : 200
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : K Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic



Product Data

• UPC : 786679349045
• GTIN : 00786679349045
• Country of Origin : Dominican Republic
• Dimensions : 4.1 in x 5.5 in x 5.5 in (Length/Depth x Height x Width)
• Weight : 11.5
• Certification : UL Listed
