JT3125TV - Cutler Hammer 125A 3 Pole Thermal Magnetic Trip Unit for JT Frame Series C Circuit Breaker

JT3125TV

JT3125TV is a thermal magnetic trip unit designed for Cutler Hammer JT frame series C molded case circuit breakers with a 125 amp rating and three poles.

This trip unit features fixed thermal and adjustable magnetic protection calibrated for 50°C, suitable for JT frame breakers. It is UL Listed and provides reliable trip functions to protect electrical circuits from overload and short circuit conditions. The unit is designed for use with 600 VAC systems and is part of Eaton's Series C product line.

• Amperage Rating: 125A
• Number of Poles: 3
• Trip Type: Fixed thermal, adjustable magnetic
• Frame Size: JT (Series C)
• Calibration Temperature: 50°C
• Certifications: UL Listed
• Voltage Rating: 600 VAC
• Trip Unit Type: Thermal magnetic
• Mounting: Compatible with JT frame molded case circuit breakers
• Country of Origin: Dominican Republic

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JT3125TV
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Trip Units & Programmers
• Family : Series C
• Type : JT
• Voltage : 600
• Poles : 3
• Functions : LI - Long-Time and Instantaneous
• Amperage Maximum : 125
• Amperage Minimum : 125
• Protection : Thermal Magnetic
• Compatible Frames : HJDDC,JD,HJD,JDC

Product Data

• UPC : 786679404287
• GTIN : 00786679404287
• Country of Origin : Dominican Republic
• Dimensions : 6.9 in x 5.3 in x 4.3 in (Length/Depth x Height x Width)
• Weight : 1.25
• Certification : UL Listed
