JT2200T - Cutler Hammer Series C 200A Two-Pole Thermal-Magnetic Trip Unit

JT2200T

JT2200T is a molded case circuit breaker accessory trip unit designed for Series C J-frame applications requiring reliable thermal-magnetic protection.

This trip unit features fixed thermal and adjustable magnetic trip characteristics, making it suitable for panelboard, switchboard, motor control center, and busway applications. The JT-type trip unit is non-interchangeable and rated for 600 VAC maximum system voltage. It has been proven through over 20 years of user acceptance and meets or exceeds North American standards for branch circuit protection.

• Amperage Rating: 200 A
• Number of Poles: Two-pole
• Frame Size: Frame J-K
• Series: Series C
• Trip Type: Thermal-magnetic (fixed thermal, adjustable magnetic)
• Circuit Breaker Type: JT
• Maximum Voltage: 600 VAC
• Certifications: UL Listed
• Product Dimensions: 7 in length, 5.3 in width, 4.3 in height
• Product Weight: 1.2 lb
• Warranty: One year from installation or eighteen months from shipment, whichever occurs first

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JT2200T
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Trip Units & Programmers
• Family : Series C
• Type : JT
• Voltage : 600
• Poles : 2
• Functions : LI - Long-Time and Instantaneous
• Amperage Maximum : 200
• Amperage Minimum : 200
• Protection : Thermal Magnetic
• Compatible Frames : HJDDC,JD,HJD,JDC

Product Data

• UPC : 786679404065
• GTIN : 00786679404065
• Country of Origin : Dominican Republic
• Dimensions : 7 in x 4.3 in x 5.3 in (Length/Depth x Height x Width)
• Weight : 1.2
• Certification : UL Listed
