JJA262001 - Square D 200A 600VAC 2-Pole PowerPact J-Frame I-Line Molded Case Circuit Breaker

JJA262001

JJA262001 is a Square D PowerPact J-Frame molded case circuit breaker designed for reliable overload and short circuit protection.This 2-pole breaker features a 200 ampere rating with a voltage capacity of 600 VAC and 250 VDC. It uses a thermal-magnetic trip unit with a trip range of 1000 to 2000 A and an interrupt rating of up to 25 kA at 600 VAC. The breaker mounts via a plug-in I-Line system and supports wire sizes from 3/0 AWG to 350 kcmil aluminum or copper. It is UL, CSA, and CE certified and suitable for 50/60 Hz frequency applications.

• Amperage: 200 A
• Voltage Rating: 600 VAC / 250 VDC
• Poles: 2
• Interrupt Rating: 25 kA at 600 VAC
• Frame: J-Frame
• Trip Unit: Thermal Magnetic
• Mounting Type: Plug-In I-Line
• Wire Size Range: 3/0 AWG to 350 kcmil Al/Cu
• Frequency: 50/60 Hz
• Certifications: UL, CSA, CE
• Actuator Type: Toggle
• Country of Origin: US

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JJA262001
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JJA
• Voltage : 600
• Amperage : 200
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : I-Line, Lug
• Frame Size : J
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 3/0 AWG (Cu/Al) Max. Wire Size 350 kcmil (Cu/Al)
• Protection : Thermal Magnetic
• Phase Connection : AB

Product Data

• UPC : 785901795742
• GTIN : 00785901795742
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 6.451
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
