Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
JGS3200FAG
JGS3200FAG is a Cutler Hammer (Eaton) molded case circuit breaker designed for reliable power distribution in commercial and industrial applications.
This three-pole breaker features a 200A current rating, 600V voltage rating, and a JG frame. It offers a fixed thermal/adjustable magnetic trip unit for enhanced protection and flexibility. The JGS3200FAG is part of the Series G line and is certified to UL, CSA, CE, and IEC standards, ensuring compliance with international safety requirements.
-
Key Specifications
- Part Number: JGS3200FAG
- Manufacturer: Cutler Hammer (Eaton)
- Amperage: 200A
- Voltage: 600V
- Poles: 3
- Mounting Type: Fixed
- Interrupt Rating: 85kA @ 240V, 35kA @ 480V, 18kA @ 600V
- Series/Frame: Series G, JG Frame
- Trip Unit: Fixed Thermal/Adjustable Magnetic
- Certifications: UL, CSA, CE, IEC
- Connection: Feed-Thru
- Phase: 3
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: JGS3200FAG
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : JGS
- Voltage : 600
- Amperage : 200
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Terminal Connection : Line/Load Lug
- Frame Size : 250A/JG
- Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
- MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
- Breaker Type : Standard
- Protection : Thermal Magnetic
- Phase Connection : ABC
Product Data
- UPC : 782113526799
- GTIN : 00782113526799
- Country of Origin : Dominican Republic
- Dimensions : 3.57 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 6
- Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
- Standards : CSA Certified, IEC Rated, UL Listed
- Certification : CSA Certified, IEC Rated, UL Listed
