JGS3175FAG - Cutler Hammer 175A 600V 3 Pole Molded Case Circuit Breaker, Series G, 35kA@480V

JGS3175FAG

JGS3175FAG is a three-pole, 175 amp, 600 volt molded case circuit breaker from the Eaton Series G line, designed for reliable protection in commercial and industrial applications. This breaker features a thermal magnetic trip unit and is rated for 35kA interrupting capacity at 480V. It is suitable for bolt-on mounting and offers robust performance in demanding environments. The JGS3175FAG breaker is built to meet rigorous safety standards and is ideal for use in panelboards and switchgear where dependable circuit protection is required. Its Series G frame provides compatibility with a wide range of electrical systems, and the fixed thermal, adjustable magnetic trip unit allows for precise coordination with downstream devices.

• Part Number: JGS3175FAG
• Manufacturer: Cutler Hammer (Eaton)
• Series/Frame: Series G
• Poles: 3
• Amperage: 175A
• Voltage: 600V
• Interrupt Rating: 35kA@480V
• Mounting Type: Bolt-On
• Frame Size: JG
• Trip Unit: Fixed Thermal, Adjustable Magnetic
• Application: Commercial, Industrial
• Certifications: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JGS3175FAG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : JGS
• Voltage : 600
• Amperage : 175
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Line/Load Lug
• Frame Size : 250A/JG
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 782113963334
• GTIN : 00782113963334
• Country of Origin : Dominican Republic
• Dimensions : 3.57 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 6
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
