JGS3125FAG - Cutler Hammer 3 Pole 125A 600V Molded Case Circuit Breaker Feed-Thru Thermal Magnetic

JGS3125FAG

JGS3125FAG is a 3 pole, 125A, 600V molded case circuit breaker from Cutler Hammer, featuring feed-thru connections and thermal magnetic protection for reliable circuit interruption. This Eaton Series G JG-frame circuit breaker is designed for industrial and commercial applications, offering long-time and instantaneous trip functions, line and load side lug terminals, and a compact footprint for space-saving installations. The breaker is rated for 35kAIC at 480V and 18kAIC at 600V, with a 125A continuous current rating and 600V AC operation.

• Part Number: JGS3125FAG
• Manufacturer: Cutler Hammer
• Series/Frame: Series G, JG-frame
• Poles: 3
• Amperage: 125A
• Voltage: 600V AC
• Mounting Type: Feed-Thru
• Interrupt Rating: 35kAIC @ 480V, 18kAIC @ 600V
• Trip Unit: Fixed Thermal, Adjustable Magnetic
• Protection Type: Thermal Magnetic
• Standards: UL 489, CSA 22.2 No. 5
• Phase: 3 Phase

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JGS3125FAG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : JGS
• Voltage : 600
• Amperage : 125
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 782113963327
• GTIN : 00782113963327
• Country of Origin : Dominican Republic
• Dimensions : 3.57 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 6
• Certification : UL Listed,IEC Rated,CSA Certified,CE Marked
