JGH3175FAG - Cutler Hammer 175A 600V 3-Pole Molded Case Circuit Breaker Series G

JGH3175FAG

JGH3175FAG is a Cutler Hammer Series G molded case circuit breaker rated for 175 amps, 600 volts, and three poles.This Eaton Cutler Hammer circuit breaker features thermal magnetic trip protection with adjustable magnetic and fixed thermal trip units. It supports line/load connections with metric mounting hardware and offers high interrupt ratings of 100 kAIC at 240V, 70 kAIC at 415V, 65 kAIC at 480V, and 25 kAIC at 600V. The breaker is UL listed, CSA certified, IEC rated, and CE marked.

Key Specifications
• Amperage: 175 A
• Voltage Rating: 600 V AC
• Poles: 3
• Series/Frame: Series G
• Interrupt Rating: 100 kAIC @ 240V, 70 kAIC @ 415V, 65 kAIC @ 480V, 25 kAIC @ 600V
• Trip Unit: Thermal Magnetic (Fixed Thermal, Adjustable Magnetic)
• Mounting Type: Line/Load with Metric Hardware
• Certifications: UL Listed, CSA Certified, IEC Rated, CE Marked
• Connection Type: Feed-Thru
• Dimensions (HxWxD): 4.13" x 4.13" x 3.57"
• Weight: 6 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JGH3175FAG
• Manufacturer : Cutler Hammer
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : JGH
• Voltage : 600
• Amperage : 175
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Line/Load Lug
• Frame Size : 250A/JG
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 782113963686
• GTIN : 00782113963686
• Country of Origin : Dominican Republic
• Dimensions : 3.57 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 6
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
