JGH3125FAG - Cutler Hammer 125A 600VAC 3-Pole JG-Frame Molded Case Circuit Breaker

JGH3125FAG

JGH3125FAG is a Cutler Hammer Series G complete molded case circuit breaker designed for three-phase power distribution applications requiring reliable overcurrent protection. This JG-frame breaker combines fixed thermal and adjustable magnetic trip technology to deliver precise protection across a wide range of electrical systems. The compact design frees up valuable panel space while maintaining superior performance through patented contact design with high-speed blow-open action. Key Specifications

• Amperage: 125 Amp
• Voltage: 600 VAC
• Poles: Three Pole
• Frame Type: JG Frame
• Trip Unit: Fixed Thermal, Adjustable Magnetic
• Interrupt Rating: 100 kA at 240 Volt, 65 kA at 480 Volt, 25 kA at 600 Volt
• Frequency: 50/60 Hz
• Certifications: UL, CSA, IEC, CCC, CE
• Connection: Line and Load
• Mounting Hardware: Included

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JGH3125FAG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : JGH
• Voltage : 600
• Amperage : 125
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 782113963419
• GTIN : 00782113963419
• Country of Origin : Dominican Republic
• Dimensions : 3.57 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 6
• Certification : IEC Rated,CSA Certified,UL Listed,CE Marked
