JGH3090FAG - Cutler Hammer 90 Amp 600 Volt 3-Pole Molded Case Circuit Breaker JG Frame

JGH3090FAG

JGH3090FAG is a 90 amp, 3-pole molded case circuit breaker from Cutler Hammer designed for 600 volt applications.This JG frame breaker features fixed thermal and adjustable magnetic trip units, suitable for line and load side installation. It offers high interrupt ratings of 100 kA at 240 V, 65 kA at 480 V, and 25 kA at 600 V, ensuring reliable protection in demanding electrical environments. The breaker supports both AC and DC voltages up to 600 VAC and 250 VDC respectively, and operates at 50/60 Hz.

• Amperage: 90 Amp
• Poles: 3
• Maximum Voltage: 600 VAC / 250 VDC
• Interrupt Rating: 100 kA @ 240 V, 65 kA @ 480 V, 25 kA @ 600 V
• Frame Type: JG Frame
• Trip Unit: Fixed Thermal, Adjustable Magnetic
• Mounting: Line and Load
• Frequency: 50/60 Hz
• Manufacturer: Cutler Hammer (Eaton)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JGH3090FAG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : JGH
• Voltage : 600
• Amperage : 90
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 782113963341
• GTIN : 00782113963341
• Country of Origin : Dominican Republic
• Dimensions : 3.44 in x 7 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 6
• Certification : CSA Certified,UL Listed,IEC Rated,CE Marked
