Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
JGE3125FAG
JGE3125FAG is a Cutler Hammer JG frame molded case circuit breaker designed for reliable protection in commercial and industrial applications.This 3-pole, 125A, 600V circuit breaker features adjustable magnetic and fixed thermal trip functionality, offering flexible protection for a wide range of electrical systems. The JGE3125FAG is built with a compact design for efficient panel space utilization and supports line/load connections for easy installation.
- Part Number: JGE3125FAG
- Manufacturer: Cutler Hammer
- Series/Frame: JG Frame
- Amperage: 125A
- Voltage: 600V AC
- Poles: 3
- Interrupt Rating: 65kA at 240V, 25kA at 480V, 18kA at 600V
- Mounting Type: Panel Mount
- Trip Unit: Adjustable Magnetic/Fixed Thermal
- Frequency: 50/60 Hz
- Dimensions: 3.57 x 4.13 x 4.13 in
- Rated: 80%
Specifications
- Part Number: JGE3125FAG
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : JGE
- Voltage : 600
- Amperage : 125
- Phase : 3
- Poles : 3
- AIC rating : 25kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 782113962559
- GTIN : 00782113962559
- Country of Origin : Dominican Republic
- Dimensions : 3.57 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 6
- Certification : CSA Certified,UL Listed,IEC Rated,CE Marked
