JGDN100 - Cutler Hammer NEMA 12 100A 600VAC Circuit Breaker Enclosure

JGDN100

JGDN100 is an Eaton NEMA 12 circuit breaker enclosure rated for 100 amperes at 600VAC, designed for surface mounting applications with C-series construction. This enclosed circuit breaker enclosure accommodates FD, FDB, HFD, EHD, and EDC series circuit breakers, featuring knockouts for flexible installation and built-in ground fault protection down to 20 amperes. The enclosure supports a wide variety of internal and external accessory combinations to meet diverse electrical distribution requirements.

• Catalog Number: JGDN100
• Amperage Rating: 100A
• Voltage Rating: 600VAC
• Enclosure Type: NEMA 12/12K
• Series: C-Series
• Mounting Method: Surface Mount
• Dimensions: 11.88 in W x 10.22 in D x 37.53 in H
• Weight: 19 lb
• Ground Fault Protection: Down to 20A
• Certifications: UL Listed, CSA Certified
• Compatible Breakers: FD, FDB, HFD, EHD, EDC

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

Please note that circuit breakers are not included with the enclosures and must be purchased separately.

Specifications

• Part Number: JGDN100
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Enclosure
• Family : Series C
• Type : JGDN
• Voltage : 600
• Amperage : 100
• Nema Rating : 12
• Compatible Frames : GC,GHC,GD,GHCGFEP

Product Data

• UPC : 782114221068
• GTIN : 00782114221068
• Country of Origin : United States
• Dimensions : 10.22 in x 37.53 in x 11.88 in (Length/Depth x Height x Width)
• Weight : 37
• Certification : CSA Certified,UL Listed
