JDC3100 - Westinghouse 3 Pole 100A 600V Molded Case Circuit Breaker Bolt-On Mounting 22kA@480V

JDC3100

JDC3100 is a 3 pole, 100 amp, 600V molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems. This Westinghouse breaker features bolt-on mounting and a high interrupting capacity for demanding applications. The JDC3100 is part of the JD series frame and uses a thermal magnetic trip unit for dependable overcurrent protection. It is suitable for use in panelboards and switchboards where robust circuit protection is required. This breaker meets UL 489 and UL 1066 standards for safety and performance.

• Part Number: JDC3100
• Manufacturer: Westinghouse
• Series/Frame: JD
• Poles: 3
• Amperage: 100A
• Voltage: 600VAC, 250VDC
• Mounting Type: Bolt-On
• Interrupt Rating: 22kA@480V
• Frame Type: JD
• Trip Unit: Thermal Magnetic
• Certifications: UL 489, UL 1066
• Application: Panelboard, Switchboard

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JDC3100
• Manufacturer : Westinghouse
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : JDC
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Frame Size : J Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679340783
• GTIN : 00786679340783
• Country of Origin : Dominican Republic
• Dimensions : 4.06 in x 10 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 14.25
• Certification : UL Listed
