JDB3175W - Eaton 175A 600V 3 Pole Molded Case Circuit Breaker J Frame 35kA@480V

JDB3175W

JDB3175W is a 3 pole, 600V, 175A molded case circuit breaker from Eaton's Series C, designed for industrial power distribution applications. This Eaton JDB3175W circuit breaker features a J frame, fixed thermal and magnetic trip, and is rated for 35kA interrupt at 480V. It is UL Listed and suitable for use in systems requiring reliable protection and high interrupt capacity.

• Part Number: JDB3175W
• Manufacturer: Eaton
• Series: Series C
• Frame: J
• Amperage Rating: 175A
• Voltage Rating: 600V AC, 250V DC
• Poles: 3
• Interrupt Rating: 35kA @ 480V
• Mounting Type: Bolt-On
• Terminals: Without terminals
• Frequency Rating: 50/60 Hz
• Trip Type: Fixed thermal, fixed magnetic
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: JDB3175W
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : JDB
• Voltage : 600
• Amperage : 175
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 078667951629
• GTIN : 00786679516294
• Country of Origin : Dominican Republic
• Dimensions : 4.06 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 11.25
• Certification : UL Listed
