JDB3125X - Eaton Series C 125A 600V 3-Pole Molded Case Circuit Breaker

JDB3125X

JDB3125X is an Eaton Series C complete molded case circuit breaker designed for industrial and commercial power distribution applications requiring reliable overcurrent protection. JDB3125X features a J-frame design with fixed thermal and fixed magnetic trip units, delivering consistent performance in demanding electrical environments. This three-pole breaker is rated for 125 amperes at 600 volts AC, with interrupt ratings of 65KA at 240VAC, 35KA at 480VAC, and 18KA at 600VAC, making it suitable for a wide range of circuit protection needs. The complete breaker assembly includes load terminals and is engineered to meet industry standards for molded case circuit breakers.

• Amperage Rating: 125A
• Voltage Rating: 600 Vac, 250 Vdc
• Poles: Three-Pole
• Frame Type: J-Frame
• Trip Unit: Fixed Thermal, Fixed Magnetic
• Series: Eaton Series C
• Interrupt Rating: 65KA @ 240VAC, 35KA @ 480VAC, 18KA @ 600VAC
• Circuit Breaker Type: Molded Case
• Product Width: 4.13 inches
• Product Height: 4.13 inches
• Weight: 11.25 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JDB3125X
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : JDB
• Voltage : 600
• Amperage : 125
• Phase : 3
• Poles : 3
• AIC rating : @480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 782114740491
• GTIN : 00782114740491
• Country of Origin : Dominican Republic
• Dimensions : 4.06 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 11.25
• Certification : UL Listed
