JDB2175W - Eaton 175A 600Vac 2-Pole Series C J-Frame Molded Case Circuit Breaker Without Terminals

JDB2175W

JDB2175W is a 175 amp, 2-pole molded case circuit breaker from Eaton's Series C J-frame lineup designed for industrial electrical protection.

This circuit breaker features a fixed thermal and fixed magnetic trip unit, providing reliable overcurrent protection. It is rated for 600 Vac and 250 Vdc operation, with a 65 kA interrupt rating at 240 Vac. The breaker comes without terminals and is UL Listed, ensuring compliance with safety standards. Its compact J-frame design supports mounting flexibility in electrical panels.

• Amperage Rating: 175 A
• Voltage Rating: 600 Vac, 250 Vdc
• Number of Poles: 2
• Interrupt Rating: 65 kAIC at 240 Vac
• Frame Type: J-frame
• Series: Series C
• Trip Type: Fixed thermal, fixed magnetic
• Terminals: Without terminals
• Certifications: UL Listed
• Frequency Rating: 50 to 60 Hz
• Product Dimensions: 4.13 in (H) x 4.06 in (D) x 4.13 in (W)
• Weight: 11.25 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: JDB2175W
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : JDB
• Voltage : 600
• Amperage : 175
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679516119
• GTIN : 00786679516119
• Country of Origin : Dominican Republic
• Dimensions : 4.06 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 11.25
• Certification : UL Listed
