Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
JDB2100W
JDB2100W is an Eaton Series C complete molded case circuit breaker designed for industrial circuit protection in low voltage distribution systems. This J-frame breaker features fixed thermal and fixed magnetic trip protection with a two-pole configuration rated for 100 amperes at 600 Vac and 250 Vdc. The unit comes without terminals and is suitable for 50/60 Hz applications. Key Specifications
- Amperage Rating: 100 A
- Voltage Rating: 600 Vac, 250 Vdc
- Number of Poles: Two-pole
- Circuit Breaker Type: JDB
- Frame: J-frame, Series C
- Trip Type: Fixed thermal, fixed magnetic
- Terminals: Without terminals
- Frequency Rating: 50/60 Hz
- Certifications: UL Listed
- Product Dimensions: 4.13 in W x 4.13 in H x 4.06 in D
- Product Weight: 11.25 lb
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: JDB2100W
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : JDB
- Voltage : 600
- Amperage : 100
- Phase : 1
- Poles : 2
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : J Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679516058
- GTIN : 00786679516058
- Country of Origin : Dominican Republic
- Dimensions : 4.06 in x 10 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 11.25
- Certification : UL Listed
