Product Info
- Manufacturer:Siemens
- Sub-Category:Trip Units & Programmers
Description
JD62T350
JD62T350 is a Siemens 2 pole thermal magnetic circuit breaker trip unit rated for 350 amps and 600 volts AC.JD62T350 features long-time and instantaneous trip functions with interchangeable trip capability. It is designed for use with Siemens JD frame molded case circuit breakers and provides a 25kA interrupt rating at 480V. The trip unit mounts with bolt-on installation and includes load side lug terminals.
- Manufacturer: Siemens
- Amperage: 350A
- Voltage: 600V AC
- Poles: 2
- Frame Type: JD
- Trip Unit Type: Thermal Magnetic
- Trip Functions: Long-Time and Instantaneous (LI)
- Interrupt Rating: 25kA at 480V
- Mounting Type: Bolt-On
- Load Side Lug Terminals
Specifications
- Part Number: JD62T350
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Trip Units & Programmers
- Family : Sentron Series
- Type : JD
- Voltage : 600
- Amperage : 350
- Phase : 1
- Poles : 2
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI - Long Time and Instantaneous Trip
- Frame Size : 350
- Temp Rating : -13¡F-158¡F (-25¡C - 70¡C)
- Amperage Maximum : 350
- Protection : Thermal Magnetic
- Compatible Frames : JD,HJD,HJXD,HHJD,HHJXD
Product Data
- UPC : 783643213289
- GTIN : 00783643213289
- Country of Origin : Mexico
- Weight : 2.2
- Standards : RoHS
- Certification : UL, IEC
- Wire Size : AWG 3/0 to 500KCM, Cu, AWG 4/0 to 500KCM, Al
