HU661AWK - Square D Heavy Duty Non-Fusible Disconnect Switch 600V 30A 6P NEMA 3R/12

HU661AWK

HU661AWK is a heavy duty, non-fusible disconnect switch designed for reliable and safe power isolation in demanding environments. This Square D switch features a robust steel enclosure with a galvannealed finish, providing durability and protection against harsh conditions. The switch is rated for 600 volts AC/DC, 30 amps, and 6 poles, making it suitable for a wide range of industrial and commercial applications. It includes a quick-make, quick-break operating mechanism, dual cover interlock, and color-coded indicator handle for enhanced safety and ease of use. The HU661AWK is UL approved and meets NEMA 3R/12 standards, ensuring compliance with industry requirements. This heavy duty safety switch is built for surface mounting and offers a minimum of three times the mechanical endurance required by NEMA KS1 and UL 98 standards. The design incorporates an abundance of copper in the current-carrying paths, which helps manage internal temperatures and extends service life. The switch is suitable for use in environments where protection against dust, dirt, and water is necessary.

• Part Number: HU661AWK
• Manufacturer: Square D
• Amperage Rating: 30 A
• Voltage Rating: 600 V AC/DC
• Poles: 6
• Mounting Type: Surface
• Interrupt Rating: 600 V
• Series/Frame: Heavy Duty
• Enclosure Type: NEMA 3R/12
• Operating Mechanism: Quick-make, quick-break
• Handle Type: Color-coded indicator
• Certifications: UL, NEMA 3R/12

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HU661AWK
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Switch
• Item Subcategory : Disconnect
• Family : Series E
• Type : HU
• Voltage : 600 AC
• Amperage : 30
• Phase : 3
• Poles : 6
• AIC rating : 200kA@600V
• Configuration : Single
• Switch Style : Non-Fusible
• Nema Rating : NEMA 12
• Compatible Frames : NSX

Product Data

• UPC : 785901868354
• GTIN : 00782113207063
• Country of Origin : United States
• Dimensions : 20.5 in (520.7 mm) x 16.13 in (409.70 mm) x 6.8 in (172.7 mm) (Height x Width x Depth)
• Weight : 29.85
• Certification : UL listed
