HU366R - Square D Heavy Duty Non-Fusible Safety Switch, 600A, 600V, 3 Pole, NEMA 3R, Surface Mount, E4 Series, 200kA Interrupt, UL Listed

HU366R

HU366R is a Square D heavy duty, non-fusible safety switch designed for reliable disconnecting in demanding commercial and industrial environments.

This safety switch features a robust galvannealed steel enclosure rated NEMA 3R for indoor/outdoor use, surface mounting, and is engineered for maximum performance and service continuity. It is suitable for applications requiring high amperage and voltage handling with no factory-installed neutral.

Key Specifications
• Amperage: 600A
• Voltage: 600V AC/DC
• Poles: 3
• Mounting Type: Surface
• Interrupt Rating: 200kA
• Series/Frame: E4 Series
• Trip Unit: Not applicable (non-fusible)
• Certifications: UL Listed
• Enclosure: NEMA 3R, rainproof, sleetproof, iceproof
• Contact Form: 3PST (Three Pole, Single Throw)
• Terminal Type: Lug
• Wire Size: #3/0 to 500 kcmil (Al/Cu)
• Finish: Galvannealed steel

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HU366R
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Switch
• Item Subcategory : Disconnect
• Family : Series E
• Type : HU
• Voltage : 600 AC
• Amperage : 600
• Phase : 3
• Poles : 3
• AIC rating : 200kA@600V
• Configuration : Single
• Switch Style : Non-Fusible
• Nema Rating : NEMA 3R
• Compatible Frames : ED

Product Data

• UPC : 785901452164
• GTIN : 00785901452164
• Country of Origin : Mexico
• Dimensions : 50.31 in (1277.87 mm) x 27.88 in (708.15 mm) x 10.13 in (257.30 mm) (Height x Width x Depth)
• Weight : 168 lb
• Certification : UL listed
